Soft/rubber valve
2-way pediatric, Length 270mm
Item No./Cat. No. | Size | Balloon volume | Color coding |
Silicone coated | Hydrophilic coated | Anti-microbial coated | PTFE coated Hydrophobic
| Golden color | FR/CH | ml/cc |
|
EC010106R | EC010106HR | EC010106MR | EC010106CR | EC010106GR | 6 | 3 | Light red |
EC010108R | EC010108HR | EC010108MR | EC010108CR | EC010108GR | 8 | 3-5/5 | Black |
EC010110R | EC010110HR | EC010110MR | EC010110CR | EC010110GR | 10 | 3-5/5 | Grey |
Hard/plastic valve
2-way pediatric, Length 270mm
Item No./Cat. No. | Size | Balloon volume | Color coding |
Silicone coated | Hydrophilic coated | Anti-microbial coated | PTFE coated Hydrophobic
| Golden color | FR/CH | ml/cc |
|
EC010106P | EC010106HP | EC010106MP | EC010106CP | EC010106GP | 6 | 3 | Light red |
EC010108P | EC010108HP | EC010108MP | EC010108CP | EC010108GP | 8 | 3-5/5 | Black |
EC010110P | EC010110HP | EC010110MP | EC010110CP | EC010110GP | 10 | 3-5/5 | Grey |
Soft/rubber valve
2-way standard, Length 400mm
Item No./Cat. No. | Size | Balloon volume | Color coding |
Silicone coated | Hydrophilic coated | Anti-microbial coated | PTFE coated Hydrophobic
| Golden color | FR/CH | ml/cc |
|
EC010212R | EC010212HR | EC010212MR | EC010212CR | EC010212GR | 12 | 5-15 | White |
EC010214R | EC010214HR | EC010214MR | EC010214CR | EC010214GR | 14 | 5-15 | Green |
EC010216R | EC010216HR | EC010216MR | EC010216CR | EC010216GR | 16 | 5-15/30 | Orange |
EC010218R | EC010218HR | EC010218MR | EC010218CR | EC010218GR | 18 | 5-15/30 | Red |
EC010220R | EC010220HR | EC010220MR | EC010220CR | EC010220GR | 20 | 5-15/30 | Yellow |
EC010222R | EC010222HR | EC010222MR | EC010222CR | EC010222GR | 22 | 5-15/30 | Violet/purple |
EC010224R | EC010224HR | EC010224MR | EC010224CR | EC010224GR | 24 | 30/30-50 | Blue |
EC010226R | EC010226HR | EC010226MR | EC010226CR | EC010226GR | 26 | 30/30-50 | Pink |
EC010228R | EC010228HR | EC010228MR | EC010228CR | EC010228GR | 28 | 30/30-50 | Brown |
EC010230R | EC010230HR | EC010230MR | EC010230CR | EC010230GR | 30 | 30/30-50 | Grey |
Hard/plastic valve
2-way standard, Length 400mm
Item No./Cat. No. | Size | Balloon volume | Color coding |
Silicone coated | Hydrophilic coated | Anti-microbial coated | PTFE coated Hydrophobic
| Golden color | FR/CH | ml/cc |
|
EC010212P | EC010212HP | EC010212MP | EC010212CP | EC010212GP | 12 | 5-15 | White |
EC010214P | EC010214HP | EC010214MP | EC010214CP | EC010214GP | 14 | 5-15 | Green |
EC010216P | EC010216HP | EC010216MP | EC010216CP | EC010216GP | 16 | 5-15/30 | Orange |
EC010218P | EC010218HP | EC010218MP | EC010218CP | EC010218GP | 18 | 5-15/30 | Red |
EC010220P | EC010220HP | EC010220MP | EC010220CP | EC010220GP | 20 | 5-15/30 | Yellow |
EC010222P | EC010222HP | EC010222MP | EC010222CP | EC010222GP | 22 | 5-15/30 | Violet/purple |
EC010224P | EC010224HP | EC010224MP | EC010224CP | EC010224GP | 24 | 30/30-50 | Blue |
EC010226P | EC010226HP | EC010226MP | EC010226CP | EC010226GP | 26 | 30/30-50 | Pink |
EC010228P | EC010228HP | EC010228MP | EC010228CP | EC010228GP | 28 | 30/30-50 | Brown |
EC010230P | EC010230HP | EC010230MP | EC010230CP | EC010230GP | 30 | 30/30-50 | Grey |
Soft/rubber valve
2-way female, Length 240mm
Item No./Cat. No. | Size | Balloon volume | Color coding |
Silicone coated | Hydrophilic coated | Anti-microbial coated | PTFE coated Hydrophobic
| Golden color | FR/CH | ml/cc |
|
EC010312R | EC010312HR | EC010312MR | EC010312CR | EC010312GR | 12 | 5-15 | White |
EC010314R | EC010314HR | EC010314MR | EC010314CR | EC010314GR | 14 | 5-15 | Green |
EC010316R | EC010316HR | EC010316MR | EC010316CR | EC010316GR | 16 | 5-15/30 | Orange |
EC010318R | EC010318HR | EC010318MR | EC010318CR | EC010318GR | 18 | 5-15/30 | Red |
EC010320R | EC010320HR | EC010320MR | EC010320CR | EC010320GR | 20 | 5-15/30 | Yellow |
EC010322R | EC010322HR | EC010322MR | EC010322CR | EC010322GR | 22 | 5-15/30 | Violet/purple |
Hard/plastic valve
2-way female Length 240mm
Item No./Cat. No. | Size | Balloon volume | Color coding |
Silicone coated | Hydrophilic coated | Anti-microbial coated | PTFE coated Hydrophobic
| Golden color | FR/CH | ml/cc |
|
EC010312P | EC010312HP | EC010312MP | EC010312CP | EC010312GP | 12 | 5-15 | White |
EC010314P | EC010314HP | EC010314MP | EC010314CP | EC010314GP | 14 | 5-15 | Green |
EC010316P | EC010316HP | EC010316MP | EC010316CP | EC010316GP | 16 | 5-15/30 | Orange |
EC010318P | EC010318HP | EC010318MP | EC010318CP | EC010318GP | 18 | 5-15/30 | Red |
EC010320P | EC010320HP | EC010320MP | EC010320CP | EC010320GP | 20 | 5-15/30 | Yellow |
EC010322P | EC010322HP | EC010322MP | EC010322CP | EC010322GP | 22 | 5-15/30 | Violet/purple |
Soft/rubber valve
2-way tiemann, Length 400mm
Item No./Cat. No. | Size | Balloon volume | Color coding |
Silicone coated | Hydrophilic coated | Anti-microbial coated | PTFE coated Hydrophobic
| Golden color | FR/CH | ml/cc |
|
EC010412TR | EC010412HR | EC010412MR | EC010412CR | EC010412GR | 12 | 5-15 | White |
EC010414TR | EC010414HR | EC010414MR | EC010414CR | EC010414GR | 14 | 5-15 | Green |
EC010416TR | EC010416HR | EC010416MR | EC010416CR | EC010416GR | 16 | 5-15/30 | Orange |
EC010418TR | EC010418HR | EC010418MR | EC010418CR | EC010418GR | 18 | 5-15/30 | Red |
EC010420TR | EC010420HR | EC010420MR | EC010420CR | EC010420GR | 20 | 5-15/30 | Yellow |
EC010422TR | EC010422HR | EC010422MR | EC010422CR | EC010422GR | 22 | 5-15/30 | Violet/purple |
Hard/plastic valve
2-way tiemann, Length 400mm
Item No./Cat. No. | Size | Balloon volume | Color coding |
Silicone coated | Hydrophilic coated | Anti-microbial coated | PTFE coated Hydrophobic
| Golden color | FR/CH | ml/cc |
|
EC010412TP | EC010412HP | EC010412MP | EC010412CP | EC010412GP | 12 | 5-15 | White |
EC010414TP | EC010414HP | EC010414MP | EC010414CP | EC010414GP | 14 | 5-15 | Green |
EC010416TP | EC010416HP | EC010416MP | EC010416CP | EC010416GP | 16 | 5-15/30 | Orange |
EC010418TP | EC010418HP | EC010418MP | EC010418CP | EC010418GP | 18 | 5-15/30 | Red |
EC010420TP | EC010420HP | EC010420MP | EC010420CP | EC010420GP | 20 | 5-15/30 | Yellow |
EC010422TP | EC010422HP | EC010422MP | EC010422CP | EC010422GP | 22 | 5-15/30 | Violet/purple |
Soft/rubber valve
3-way standard, Length 400mm
Item No./Cat. No. | Size | Balloon volume | Color coding |
Silicone coated | Hydrophilic coated | Anti-microbial coated | PTFE coated Hydrophobic
| Golden color | FR/CH | ml/cc |
|
EC010516R | EC010516HR | EC010516MR | EC010516CR | EC010516GR | 16 | 5-15/30 | Orange |
EC010518R | EC010518HR | EC010518MR | EC010518CR | EC010518GR | 18 | 5-15/30 | Red |
EC010520R | EC010520HR | EC010520MR | EC010520CR | EC010520GR | 20 | 5-15/30 | Yellow |
EC010522R | EC010522HR | EC010522MR | EC010522CR | EC010522GR | 22 | 5-15/30 | Violet/purple |
EC010524R | EC010524HR | EC010524MR | EC010524CR | EC010524GR | 24 | 30/30-50 | Blue |
EC010526R | EC010526HR | EC010526MR | EC010526CR | EC010526GR | 26 | 30/30-50 | Pink |
EC010528R | EC010528HR | EC010528MR | EC010528CR | EC010528GR | 28 | 30/30-50 | Brown |
EC010530R | EC010530HR | EC010530MR | EC010530CR | EC010530GR | 30 | 30/30-50 | Grey |
Hard/plastic valve
3-way standard, Length 400mm
Item No./Cat. No. | Size | Balloon volume | Color coding |
Silicone coated | Hydrophilic coated | Anti-microbial coated | PTFE coated Hydrophobic
| Golden color | FR/CH | ml/cc |
|
EC010516P | EC010516HP | EC010516MP | EC010516CP | EC010516GP | 16 | 5-15/30 | Orange |
EC010518P | EC010518HP | EC010518MP | EC010518CP | EC010518GP | 18 | 5-15/30 | Red |
EC010520P | EC010520HP | EC010520MP | EC010520CP | EC010520GP | 20 | 5-15/30 | Yellow |
EC010522P | EC010522HP | EC010522MP | EC010522CP | EC010522GP | 22 | 5-15/30 | Violet/purple |
EC010524P | EC010524HP | EC010524MP | EC010524CP | EC010524GP | 24 | 30/30-50 | Blue |
EC010526P | EC010526HP | EC010526MP | EC010526CP | EC010526GP | 26 | 30/30-50 | Pink |
EC010528P | EC010528HP | EC010528MP | EC010528CP | EC010528GP | 28 | 30/30-50 | Brown |
EC010530P | EC010530HP | EC010530MP | EC010530CP | EC010530GP | 30 | 30/30-50 | Grey |
