Technical Parameters:

Model

BPR-5V288S

BPR-5V298

BPR-5V358S

BPR-5V368

BPR-5V468

Capacity

288L

298L

358L

368L

468L

Temp. Range

2~8℃

Temp. Accuracy

0.1℃

Temp. Uniformity

≤2℃

Temp. Stability

≤3℃

Recovery Time(Recover to 8℃ in an ambient temp. of 32℃)

≤15min

Cooling Time(Cool down to 6℃ in an ambient temp. of 32℃)

≤55min

≤120min

≤60min

≤70min

Control System

Microprocessor control

Display

LED

Alarm

High and low temperature alarm, thermostat fault alarm, door switch alarm, power failure alarm(8h)

Refrigeration Type

Air-cooling

Refrigerant

R290/80g

R600a/33g

R290/90g

R600a/45g

R290/97g

Compressor

International famous brand compressor/1

Condenser&Evaporator

Bundy tube; copper tube aluminum fin type

Bundy tube; aluminum tube aluminum fin type

Bundy tube; copper tube aluminum fin type

Bundy tube; aluminum tube aluminum fin type

Copper tube aluminum fin type

Defrost

Automatic defrost

Construction

Polyurethane cyclopentane insulation material

Material

Internal Material

Spraying steel plate

Embossed aluminum plate

Spraying steel plate

External Material

Spraying steel plate

Door

Electrically heated glass door*1

Consumption

260W

189W

260W

263W

220W

Power Supply

AC220V, 50Hz(Standard); 110V, 60Hz(Optional, external transformer); 220V, 60Hz(Optional)

AC220V, 50Hz(Standard); 110/220V, 60Hz(Optional)

AC220V, 50Hz(Standard); 110V, 60Hz(Optional, external transformer); 220V, 60Hz(Optional)

AC220V, 50Hz(Standard); 110/220V, 60Hz(Optional)

Casters

Yes

Shelf

4

5

Standard Accessory

Test hole, USB interface

Optional Accessory

RS485, printer, temperature recorder

Internal Size(W*D*H)

530*520*1096mm

530*410*1375mm

530*520*1325mm

566*475*1290mm

580*613*1325mm

External Size(W*D*H)

640*665*1658mm

620*575*1980mm

640*665*1886mm

650*600*2010mm

680*747*1885mm

Package Size(W*D*H)

770*800*1830mm

720*660*2160mm

770*800*2060mm

740*695*2230mm

830*880*2050mm

Net Weight

110kg

78kg

120kg

90kg

135kg

Gross Weight

127kg

88kg

140kg

105kg

158kg
