Features:
1. Multiple sensors design: make sure the precise monitoring and programming.
2. Unibody Design, Mono-assembly foaming(Rigid polyurethane insulation material).
3. Forced air refrigeration system, ensure inner temperature constant and uniform.
4. Adjustable shelves, improve space utilization; blood storage baskets can be classified.
5. Individual transparent inner door, effectively reduce cool air loss when opening the door.
Technical Parameters:
Model
BBR-4V86
BBR-4V136
BBR-4V296
BBR-4V356
BBR-4V466
Capacity
86L
136L
296L
356L
466L
Temp. Range
2~6℃
Temp. Accuracy
0.1℃
Temp. Uniformity
≤1.5℃
Temp. Stability
≤2℃
Recovery Time(Recover to 6℃ in an ambient temp. of 32℃)
≤15min
Cooling Time(Cool down to 5℃ in an ambient temp. of 32℃)
≤55min
≤60min
≤70min
Control System
Microprocessor control
Display
LED display
Alarm
High and low temperature, sensor&system failure alarm, door ajar alarm, power failure alarm, battery switch alarm
Refrigeration Type
Air-cooling
Refrigerant
R134a/115g
R134a/120g
R134a/175g
R134a/190g
R134a/200g
Compressor
International famous compressor/1
Condenser & Evaporator
Copper tube aluminum fin type
Defrost
Automatic defrost
Construction
Polyurethane cyclopentane foam
Material
Internal Material
Stainless steel
External Material
Sprayed steel plate
Door
Outer door: electrically heated glass semi-foam door*1
Inner door: acrylic door*2
Inner door: acrylic door*3
Outer door: electrically heated glass door*1
Consumption
245W
252W
267W
352W
506W
Power Supply
AC220V, 50Hz(Standard); AC220V, 60Hz; 110V, 60Hz(Optional, external transformer)
AC220V, 50Hz(Standard);
AC110/220V, 60Hz(Optional)
C220V, 50Hz(Standard); AC220V, 60Hz; 110V, 60Hz(Optional, external transformer)
Casters
Yes
Shelf
2pcs
4pcs
5pcs
Basket
6pcs
12pcs
15pcs
20pcs
Blood Bag(450ml)
66pcs
132pcs
156pcs
195pcs
300pcs
Standard Accessory
Thermal printer, test hole
Optional Accessory
Temperature recorder, USB interface, RS485 interface
Internal Size(W*D*H)
430*459*495mm
430*459*745mm
530*520*1096mm
530*520*1325mm
580*613*1325mm
External Size(W*D*H)
530*660*1037mm
530*660*1287mm
630*720*1658mm
630*720*1886mm
680*747*1886mm
Package Size(W*D*H)
680*740*1330mm
685*750*1560mm
780*840*1910mm
770*830*2070mm
820*910*2080mm
Net Weight
74kg
90kg
121kg
136kg
165kg
Gross Weight
103kg
120kg
160kg
175kg
199kg
